FLOW CAPACITY

Flow capacity based on light dirt load and low viscosity Actual flow rate may be lower with vessel sizing based on fluid dirt
loads, nature of contaminant, viscosity, micron rating and temperature

HIGH FLOW NOMENCLATURE INFORMATION
FILTR ATION | SEPAR ATION | PURIFICATION
Number Orien- Cartridge Inlet/ Inlet/ Pressure
Model of Filters tation Height Material Outlet Outlet Rating Gasket Options
Around (inches) Size Config.
High Flow Series HFH –1 20 R 304 SS –4 150 150 psig –B Buna-N

Series
–6
T 316 SS
–3
40
EDPM
300 300 psig –E
Filter Housings –4 60 C Carbon –8 (Consult –S Silicone
Factory)
Steel
–7
–V Viton
–12
Filter Housings for
High Flow Applications V Vertical –SS Side In/ –H Hinge
Side Out
–DA Davit Arm
Horizontal
H
HT Tipped –SB Side In/ –PA Passivation
Horizontal Bottom Out
Product Specifications Graver High Flow Series filter housings are designed to accept Graver and (1 Round Only)
Shell/O-Ring: competitive High Flow Series large geometry filter elements Available
Buna-N, EPDM, Silicone, Viton in both vertical and horizontal orientations, the High Flow housings can
Optional: accept from 1 to 7 filter elements Also available is a single round tipped Example: HFH1H40T–4–SS150–S–H
300 psig (20 6 bar) Flanged Head horizontal design that allows easier removal without the need for a platform
designs available – Consult Factory and readily drains from back of vessel to eliminate fluid spills HFH 1 H 40 T –4 –SS 150 –S –H
Not for use with compressed gases
FEATURES & BENEFITS
Operating Parameters • Industrial grade housings available in 304, HIGH FLOW HOUSING PRESSURE DROP
Maximum operating pressure: 316 and carbon steel wetted parts For Various Pipe Sizes
Carbon Steel • ASME U code available
150 psig (10 3 bar) @ 500°F (260°C) • Designs for 1, 3, 4 or 7 filters per housing
in liquid service 6
Stainless Steel for flows up to 3500 GPM* 5 6"
150 psig (10 3 bar) @ 300°F(149°C) • 150 psig designs 4"
in liquid service • Accepts 20", 40" and 60" High Flow cartridges 4
Not for use with compressed gases 8"
• Vertical and horizontal designs offered Pressure Drop (psid) 3
Available Options • Hold down plate prevents elements from
unseating due to back pressure 2 12"
• Vertical Housing Inlet/outlet • Filter removal tool available to facilitate
Side in/side out, Side in/bottom out 1
• Horizontal Housing Inlet/Outlet Side element changeout 0
in/bottom out • Swing bolts on 150 psig design
• Tilted Horizontal Side in/side out, • Equipped with 1" vent and 2" drain 0 500 1000 1500 2000 2500 3000 3500
Side in/bottom out (1" drain on tipped horizontal style)
• Gauge ports Flow Rate (GPM, Water)
• Hinged cover TYPICAL APPLICATIONS
• Davit arm • Pre RO • Food and Beverage
• Water • Pulp and Paper
• Desalination • Petrochemicals
• Oil and Gas

Content continues on next page
