Page 46 - Filter Cartridges Product Catalogue

P. 46

PME NOMENCLATURE INFORMATION

Filter Retention Rating Nominal Length End Gasket
Type (microns) (inches) Configuration or O-Ring

PME 0.2 5 –5 –29.25 * P Double Open End B Buna-N
FILTR ATION | SEPAR ATION | PURIFICATION Series 0.45 10 –9.75 * –30 P2 226/Flat Single Open End E EPDM
1 25 –10 –39 * P3 222/Flat Single Open End S Silicone
2.5 50 –19.5 * –40 P7 226/Fin Single Open End T Teflon encap Viton
PME Series Example: PME 5–10P3B –20 P8 222/Fin Single Open End V (O-Rings only)
Viton
Filter Cartridges * Available only for DOE (P) configuration –10 P3 B
PME
5

“Absolute” Rated Economical PME FLOW RATE REMOVAL EFFICIENCY

Pleated Filter Cartridges Typical Flow Rate Clean Water at Ambient Temperature Beta Ratio Beta 5000 Beta 10
(per 10" cartridge) Efficiency 99.98% 90%

0 2 µm 0 20 0 08
BAR PSI 0 2 µm
Product Specifications For applications requiring an economical solution, choose the PME Series 0 28 4 0 45 µm 0 45 0 25
Media: Polypropylene to deliver absolute efficiency in a broad range of particle sizes This all 0 21 3 1 µm 1 0 0 5
Inner core, end caps, cage: polypropylene filter is suitable for a wide range of applications and provides 2 5 µm 2 5 1 0
Polypropylene industry certifications to satisfy most critical requirements In addition, the Differential Pressure 0 14 2 0 45 µm
Gaskets/O-Rings: slightly smaller diameter ensures easy retrofit in installed housings designed 1, 2 5 µm 5 µm 5 0 1 8
5 µm
Buna-N, EPDM, Silicone, Viton, Teflon to accept depth filters The pleated construction provides high dirt holding 0 07 1 10, 25, 50 µm 10 µm 10 0 6 0
Encapsulated Viton (O-Rings only) capability and low pressure drops 0 0
Micron ratings: FEATURES & BENEFITS 0 2 4 6 8 USGPM 25 µm 25 0 11 0
0 2, 0 45, 1, 2 5, 5, 10, 25, 50 μm 0 7 6 15 1 22 7 30 3 LPM 50 µm 45 0 25 0
• Micron ratings from 0 2 to 50 μm — Broad application range
Dimensions Upstream particle counts
• 2 55" diameter to fit installed housings with ease For liquids other than water, multiply pressure drop by the fluid viscosity in centipoise Beta Ratio =
Nominal lengths: • “Absolute” Efficiency — Rated at 99 98% (Beta 5000) Downstream particle counts
5", 9 75", 10", 19 5", 20", 29 25", 30", 39", 40"
(12.7, 24.8, 25.4, 49.5, 50.8, 74.3, 76.2, • Optimized surface area — High dirt holding
99.1, 101.6 cm) for long service life The micron ratings shown at various efficiency and beta ratio value levels were determined through laboratory testing, and can be used as a guide for selecting cartridges
and estimating their performance Under actual field conditions, results may vary somewhat from the values shown due to the variability of filtration parameters
Outside diameter: 2 55" (6 48 cm) • Fixed pore structure — Eliminates dirt unloading Testing was conducted using the single-pass test method, water at 2 5 gpm/10" cartridge Contaminants included latex beads, coarse and fine test dust Removal
Inside diameter: 1 0" (2 54 cm) at maximum differential pressure efficiencies were determined using dual laser source particle counters
• Polypropylene Construction — Inert to many process fluids
Operating Parameters
• Various Gasket/O-Ring materials — Compatible with
Maximum operating temperature: a variety of fluids
176°F (80°C)
• Manufactured in continuous lengths up to 40 inches
Maximum differential pressure:
50 psid @ 70°F (3 4 bar @ 21°C)
25 psid @ 176°F (1 7 bar @ 80°C) CERTIFICATIONS
Recommended change-out pressure: • FDA Listed Materials — All materials comply with FDA Title 21 of the Code
35 psid (2 4 bar) of Federal Regulations Sections 174 5, and 177 1520, as applicable for food
and beverage contact
